Timber Materials

Introduction

Timber materials combine renewable sourcing with high strength-to-weight ratios, excellent fire endurance (via char), and low embodied carbon. For structural engineers, performance depends on species, growth characteristics, moisture content, grading, and how elements are fabricated and connected. This page explains the practical choices—from dimensional lumber and heavy timber to engineered products like glulam, LVL, PSL, LSL, and CLT—and how to match them to structural loads, analysis, and load paths through to foundations and inspections.

Right species + right product + right moisture + right connection = predictable, durable timber structures.

Species & Product Families

Timber for structures ranges from solid-sawn lumber to engineered composites that tune defects, moisture, and stiffness. Choose by availability, span, aesthetics, durability, and fabrication constraints:

  • Solid-Sawn (Dimensional & Heavy Timber): Spruce–Pine–Fir (SPF), Douglas Fir–Larch (DF-L), Southern Pine (SP). Heavy timber sections excel for long spans and exposed aesthetics.
  • Glulam (GLT): Laminated lumber bonded with structural adhesive; high strength, consistent appearance, excellent for arches and long-span beams/columns.
  • LVL / PSL / LSL: Veneer or strand-based products with reliable stiffness and strength—ideal for headers, rim boards, and heavily loaded members.
  • CLT (Cross-Laminated Timber): Orthotropic plates formed by crosswise laminations; used for floors, roofs, and walls; provides two-way action and diaphragm potential.
  • HSS/Hybrid Interfaces: Timber often pairs with steel connectors and concrete toppings; coordinate with steel design and concrete design.

Selection Tips

Use glulam for architectural long spans; LVL/PSL for high-load beams and transfer elements; CLT for plates and shear walls; heavy timber where fire endurance and exposed finish are priorities.

Grading, Design Values & Variability

Wood is anisotropic and variable. Design values are set statistically and adjusted for load duration, moisture, temperature, size, and stability. Visual or machine grading assigns grades; engineered products have manufacturer-specific properties.

Conceptual Adjustment of Design Values

\( F’ = F_b \cdot C_D \cdot C_M \cdot C_T \cdot C_F \cdot C_P \cdot C_L \)
\(F_b\)Base bending value
\(C_D\)Load duration factor
\(C_M\)Moisture factor
\(C_T, C_F, C_P, C_L\)Temperature, size, stability, column
  • Key Mechanical Properties: Bending \(F_b\), shear \(F_v\), compression parallel/perpendicular \(F_c\), modulus of elasticity \(E\), specific gravity, and density.
  • Load Duration: Wood allows higher short-term stresses (wind/seismic); coordinate with wind design and seismic design.
  • Stability: Slender columns require column stability factor; lateral-torsional buckling checks often govern beams.

Did you know?

Machine stress-rated (MSR) lumber offers tighter E and strength distributions—helpful for vibration control and long-span floors.

Moisture Content, Shrinkage & Creep

Moisture is the single most important variable for dimensional stability and durability. Wood swells with absorption and shrinks as it dries, primarily across the grain. Sustained stress and moisture lead to time-dependent creep.

Moisture Content & Equilibrium

\( \text{MC} = \dfrac{m_\text{wet}-m_\text{dry}}{m_\text{dry}} \times 100\% \quad ; \quad \text{EMC} = f(\text{RH}, T) \)
MCMoisture content
EMCEquilibrium with ambient air
  • Conditioning: Specify kiln-dried material and protect from wetting during storage and erection.
  • Shrinkage: Design for movement; use slotted holes, bearing seats, and slip details where appropriate.
  • Creep: Limit long-term stresses and deflections; composite action with concrete toppings can improve stiffness if shear transfer is ensured.

Important

Do not lock wet members into rigid frames; as they dry, restraint can split connections or crush bearing zones. Detail for movement.

Durability: Decay, Insects & Moisture Management

Biological deterioration needs moisture, oxygen, and moderate temperatures. Break the triangle by keeping wood dry, using durable species or treatments, and designing effective water management.

  • Design for Dryness: Drip edges, ventilation, capillary breaks, raised bases, and flashing. Keep end-grain out of splash zones.
  • Preservatives: Pressure treatment where exposure is unavoidable; stainless/HDG fasteners with treated lumber.
  • Detailing: Avoid water traps at steel shoes and concealed hangers; slope surfaces and allow inspection access.

Inspection Focus

Check end-grain, connections, and interfaces with concrete/steel during structural inspections—these are first points to show distress.

Connections & Fasteners

Connections control performance and constructability. Wood-to-wood and wood-to-steel joints rely on dowel action, bearing in wood, and withdrawal resistance. For engineered systems, proprietary hardware simplifies seismic and uplift detailing.

  • Bolts & Screws: Design for shear (bearing/yielding) and withdrawal; long screws enable high-angle reinforcement and composite action with CLT/glulam.
  • Nails & Plates: Effective for diaphragms and sheathing; verify spacing, edge distances, and moisture assumptions.
  • Hidden Connectors: Knife plates and slotted-in steel with rods; check perpendicular-to-grain stresses and provide reinforcement for splitting.
  • Ductility: For seismic, target ductile steel fuses with protected wood bearing; verify cyclic behavior where required.

Perpendicular-to-Grain Bearing (Concept)

\( \sigma_{\perp} \approx \dfrac{P}{A_b} \;\;\Rightarrow\;\; \text{reinforce or spread} \; P \; \text{to avoid crushing/splitting} \)
\(A_b\)Effective bearing area

Mass Timber & Engineered Wood Systems

Mass timber (CLT, glulam, NLT/DLT) enables mid- to high-rise buildings with warm aesthetics and rapid erection. Structural behavior depends on orthotropic plate action, panel rolling shear, diaphragm chords/collectors, and connections that manage uplift and transfer forces.

  • CLT Plates: Check major/minor stiffness, rolling shear in cross-layers, and vibration for comfort.
  • Glulam Beams/Columns: High stiffness and visual finishes; consider camber and long-term deflection.
  • Diaphragms & Load Path: Nail/screw patterns, metal straps, and steel connectors deliver forces to frames/cores; see load path analysis.

Floor Vibration

Serviceability often governs. Coordinate panel thickness, span, and composite toppings with structural dynamics for comfort targets.

Fire Performance & Charring

Timber chars at a predictable rate, forming an insulating layer that protects the core. Design can rely on sacrificial char depth or encapsulation with gypsum/boards to meet ratings.

Char Depth (Concept)

\( a_\text{eff} = \beta_0 \, t + a_0 \)
\(\beta_0\)Char rate (mm/min)
\(t\)Exposure time (min)
\(a_0\)Zero-strength layer allowance
  • Exposed Timber: Size members to retain residual section after charring and protect connections (often the weak link).
  • Encapsulated: Use gypsum layers to delay ignition; coordinate detailing at penetrations and interfaces.

Sustainability & Carbon

Timber stores biogenic carbon during service life and is sourced from renewable forests. Whole-building life-cycle assessment (LCA) quantifies embodied carbon; durable detailing that extends life usually beats incremental material tweaks. Consider deconstruction and reuse potential for members and panels.

Practical Levers

Specify third-party certified wood, optimize spans for panel efficiency, reduce connector count via rationalized grids, and coordinate with mechanical routing to avoid over-penetrations.

Specifications, Standards & Trusted References

Use authoritative sources for up-to-date design values, connection methods, and fire/diaphragm guidance. These stable homepages are reliable starting points:

  • American Wood Council (AWC): Design standards and manuals. Visit awc.org.
  • USDA Forest Products Laboratory: Research on wood properties and durability. Visit fpl.fs.usda.gov.
  • ASTM: Material and testing standards for wood and adhesives. Visit astm.org.
  • ICC: Building code adoption and resources. Visit iccsafe.org.

For system context, see related pages on timber design, structural dynamics, wind design, seismic design, and inspections.

QA/QC, Fabrication & Field Execution

Predictable performance depends on shop quality and site protection. Engineered wood requires fabrication within tight tolerances; connection routings and hardware must remain dry and accessible.

  1. Submittals: Product data with design values, layup schedules (for CLT/glulam), adhesives, and moisture limits.
  2. Fabrication: CNC accuracy, sealed edges for moisture, pre-drilled hardware, and protected packaging.
  3. Delivery & Storage: Keep off grade, under cover, ventilated; monitor MC with a meter and reject wet or damaged pieces.
  4. Erection: Temporary protection at cut ends and connections; manage tolerance stack-up across grids and stairs/cores.
  5. Inspection & Testing: Verify fastener patterns, torque/tension where applicable, and sealant/flashing details; plan special inspections for proprietary connectors.

Did you know?

A brief wetting during erection is normal—problems arise when moisture is trapped in concealed joints. Design details so assemblies can dry.

Common Issues & How to Avoid Them

  • Perpendicular-to-Grain Crushing: Provide bearing plates and longer seat lengths; avoid concentrated point loads into cross grain.
  • Splitting at Connections: Respect edge distances and end distances; add self-tapping screw reinforcement where necessary.
  • Excessive Vibration/Deflection: Increase depth or composite action; select MSR lumber or higher-E products; coordinate with vibration criteria.
  • Moisture Staining/Decay: Provide capillary breaks, vent cavities, and water management; protect during construction.
  • Fire Detailing Gaps: Exposed fasteners and connectors can limit rating—encapsulate or use tested hardware; ensure continuity of fire protection at joints.

Field Checklist

Confirm species/grades, measure moisture, inspect connectors and spacing, seal end-grain, verify flashing and membranes, and document as-built locations for future maintenance.

Frequently Asked Questions

Is engineered wood stronger than solid sawn?

Typically yes for bending and stiffness consistency, because defects are dispersed and layups are engineered. LVL/PSL often outperform equivalent solid sections of the same depth.

Can I leave CLT exposed and still meet fire ratings?

Often yes—design for sacrificial char and protect connections—though some occupancies require encapsulation. Coordinate with the code path and fire engineer early.

How do I control floor vibration?

Increase panel thickness or beam depth, shorten spans, add mass (toppings), or increase damping with finishes/partitions. Validate with modal checks and service criteria.

What’s the biggest moisture risk?

Trapped water at steel interfaces and concealed joints. Design drying paths and avoid flat, unvented surfaces; use membranes and drip edges generously.

Key Takeaways & Next Steps

Timber materials offer competitive strength-to-weight, fast erection, and warm aesthetics—when moisture, variability, and connections are handled thoughtfully. Choose species and engineered products that fit spans and serviceability, condition and protect materials from wetting, and design connections for ductility and inspection. For plates and tall systems, coordinate dynamic comfort and diaphragm load paths through to foundations.

Continue with our guides on timber design, compare materials in steel and concrete, and plan effective inspections. For authoritative standards and research, start at AWC, USDA Forest Products Lab, ASTM, and ICC. With the right choices and details, timber delivers robust, low-carbon structures that age gracefully.
